ANEST IWATA SOUTHEAST ASIA Co., Ltd.
Our Japanese-standard quality products
A diverse selection of Japanese-standard coating and spraying equipment suitable for general industry work, automobile parts manufacturing, electrical devices manufacturing, car body paint and spray works are available here. Our products help customers manufacture goods to their anticipated standards while having good quality work piece and being environment-friendly.
Product Detail
WS-400 + PC-G600P-2 (600ml Cup)
| Technical |  |  |  | Spray Distance |  |
|---|---|---|---|---|---|
| WS-400 -1301 B-S1 | 1.3 | WS-400-01 | 2.0 | 200 mm | 365 |
| WS-400 -1301 C-S1 | 1.3 | 365 | |||
| WS-400 -1401 B-S1 | 1.4 | 365 | |||
| WS-400 -1401 C-S1 | 1.4 | 370 | |||
| WS-400 -1301 BH-S1 | 1.3 HD (1.3.2) | 365 | |||
| WS-400 -1301 CH-S1 | 1.3 HD (1.3.2) | 365 | |||
| WS-400 -1401 BH-S1 | 1.4 HD (1.4.2) | 370 | |||
| WS-400 -1401 CH-S1 | 1.4 HD (1.4.2) | 370 | |||
| WS-400 -1501 BH-S1 | 1.5 HD (1.5.2) | 370 | |||
| WS-400 -1501 CH-S1 | 1.5 HD (1.5.2) | 370 |
Plastic case
• WS-400 Evo Clear
• Air Regulator AJR-02S-VG
• PC-G60P-2 CUP _600ml
• Plastic Gun Case
• Cleaning Brushes
• Universal Spanner
LS-400 + PC-G600P-2 (600ml Cup)
| Technical | | | |  |
|
|---|---|---|---|---|---|
| LS-400-1205 | 1.2 ET | LS-400-05 | 1.8 | Spray Distance at 200mm | 350 |
| LS-400-1305 | 1.3 ET | 350 | |||
| LS-400-1405 | 1.24ET | 360 | |||
| LS-400-1505 | 1.5 ET | 365 | |||
| LS-400-ETS12 | 1.2 ETS | 305 | |||
| LS-400-ETS13 | 1.3 ETS | 310 | |||
| LS-400-ETS14 | 1.4 ETS | 310 | |||
| LS-400-ETS15 | 1.5 ETS | 320 | |||
Plastic case
• LS-400 Entech
• Air Regulator AJR-02S-VG
• PC-G60P-2 CUP _600ml
• Plastic Gun Case
• Cleaning Brushes
• Universal Spanner
W-400WB
| Technical | | | | |
|---|---|---|---|---|
| W-400 WB-122G | 1.2 | WB2 | 1.8 | 290 |
| W-400 WB-132G | 1.3 | 300 | ||
| W-400 WB-142G | 1.4 | 310 | ||
| W-400 WB-162G | 1.6 | 340 |
W-400 Bellaria
| Technical | | | | |
|---|---|---|---|---|
| W-400 WB-104G | 1.0 | BA4-1 | 2.0 | 200 |
| W-400 WB-124G | 1.2 | 220 | ||
| W-400 WB-134G | 1.3 | BA4-2 | 280 | |
| W-400 WB-144G | 1.4 | 300 | ||
| W-400 WB-164G | 1.6 | 330 | ||
| W-400 WB-184G | 1.8 | 375 | ||
| W-400 WB-204G | 2.0 | 390 |
W-400
| Technical | | | | |
|---|---|---|---|---|
| W-400-122G | 1.2 | LV2 | 2.0 | 175 |
| W-400-132G | 1.3 | 225 | ||
| W-400-142G | 1.4 | |||
| W-400-162G | 1.6 | 270 | ||
| W-400-182G | 1.8 | LV1 | 260 | |
| W-400-251G | 2.5 | W1 | 3.0 | 340 |
WIDER Kiwami
| Model | | |  |  |  | |
|---|---|---|---|---|---|---|
| KIWAMI-1-13B8 | 1.3 | B8 | 0.20 | 185 | 230 | 260 |
| KIWAMI-1-14B8 | 1.4 | B8 | 0.20 | 200 | 230 | 275 |
WIDER4
| Model | Type of feed | | | | | | | |
|---|---|---|---|---|---|---|---|---|
| WIDER4-12J2 | Gravity | 1.2 | 0.20 | 140 | 280 | 230 | WIDER4-J2 | 355 |
| WIDER4-13J2 | 1.3 | 160 | 260 | |||||
| WIDER4-14J2 | 1.4 | 210 | 280 | |||||
| WIDER4-16J2 | 1.6 | 240 | 300 | |||||
| WIDER4-18N2 | 1.8 | 320 | 290 | 280 | WIDER4-N2 | |||
| WIDER4-25W1 | 2.5 | 0.29 | 555 | 360 | 380 | WIDER2-W1 |
Kiwami BA
| Model | | | | | | | |
|---|---|---|---|---|---|---|---|
| KIWAMI4-13BA4 | 1.3 | 0.20 | 270 | 220 | KIWAMI4-BA4 | 280 | 355 |
| KIWAMI4-14BA4 | 1.4 | 250 | 300 | ||||
| KIWAMI4-16BA4 | 1.6 | 285 | 330 | ||||
| KIWAMI4-18BA4 | 1.8 | 360 | 375 |
Kiwami WB
| Model | | | | | | | |
|---|---|---|---|---|---|---|---|
| KIWAMI4-V12WB2 | 1.2 | 0.18 | 390 | 120 | KIWAMI4-WB2 | 290 | 355 |
| KIWAMI4-V13WB2 | 1.3 | 160 | 300 | ||||
| KIWAMI4-V14WB2 | 1.4 | 310 | |||||
| KIWAMI4-V16WB2 | 1.6 | 250 | 340 |
Kiwami WBX
| Technical | | | | | | | |
|---|---|---|---|---|---|---|---|
| KIWAMI4-V13WBX | 1.3 | 0.20 | 370 | 195 | KIWAMI4-WBX | 390 | 355 |
| KIWAMI4-V14WBX | 1.4 | 200 |
LPH-80
| Technical | | | | |
|---|---|---|---|---|
| LPH-80-044G | 0.4 | E4 | 0.1 | 55 |
| LPH-80-064G | 0.6 | 80 | ||
| LPH-80-084G | 0.8 | 100 | ||
| LPH-80-104G | 1.0 | 130 | ||
| LPH-80-124G | 1.2 | 140 |
LPH-50
| Technical | | | | |
|---|---|---|---|---|
| LPH-50-102G | 1.0 | E2 | 0.9 | 100 |
PC-4S
PC-51
PCG-2D-1
PCG-6P-M
Free-angle cup
PC-400SB-2LF (Stainless)
PC-400AB-2LF (Aluminum)
PC-250SB-2LF (Stainless)
PC-150SB-2LF (Aluminum)
| Model | Capacity (ml) | Mass (g) | Connection | Applicable spray gun |
|---|---|---|---|---|
| Gravity feed cup (Side) | ||||
| PC-4S | 400 | 168 | G1/4 (PF1/4) | W-50, -101, LPH-50 |
| PC-400SB-2LF | 400 | 210 | G1/4 (PF1/4) | W-101 (free angle stainless steel cup) |
| PC-250SB-2LF | 250 | 170 | G1/4 (PF1/4) | W-101, LPH-50 (free angle stainless steel cup) |
| PC-150SB-2LF | 150 | 155 | G1/4 (PF1/4) | W-101, LPH-50 (free angle stainless steel cup) |
| PC-5 | 250 | 135 | G1/4 (PF1/4) | W-101, LPH-50 |
| PC-51 | 220 | 126 | G1/4 (PF1/4) | W-101, LPH-50 (stainless steel cup) |
| PC-61 | 130 | 110 | G1/4 (PF1/4) | W-101, LPH-50 (stainless steel cup) |
| Gravity feed cup (Center) | ||||
| PCG-6P-M | 600 | 160 | M16 X 1.5 (female) | W-400 (plastic cup) |
| PCG-2D-1 | 150 | 100 | G1/8 (PF1/8) | LPH-80 (aluminum cup) |
| PCG-600P-2 | 600 | 220 | WS-400, LS-400 (plastic cup) | |
